SCRs - Modules
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Structure | Number of SCRs, Diodes | Voltage - Off State | Current - On State (It (AV)) (Max) | Current - On State (It (RMS)) (Max) | Voltage - Gate Trigger (Vgt) (Max) | Current - Gate Trigger (Igt) (Max) | Current - Non Rep. Surge 50, 60Hz (Itsm) | Current - Hold (Ih) (Max) | Operating Temperature | Grade | Qualification | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MCMA110P1800TASCR MODULE 1.8KV 110A TO240AA |
5,528 |
|
Datasheet |
- | TO-240AA | Box | Active | Series Connection - All SCRs | 2 SCRs | 1.8 kV | 110 A | 200 A | 1.5 V | 150 mA | 1900A, 2050A | 200 mA | -40°C ~ 140°C (TJ) | - | - | Chassis Mount |
|
VW2X60-14IO1AC CONTROLL MODULE 1400V 60A |
9,704 |
|
Datasheet |
- | Module | Box | Active | 2-Phase Controller - All SCRs | 4 SCRs | 1.4 kV | 27 A | 43 A | 1.5 V | 100 mA | 520A, 560A | 200 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
MCD95-16IO1BMOD THYRISTOR/DIO 1600V TO-240AA |
8,086 |
|
Datasheet |
- | TO-240AA | Box | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 1.6 kV | 116 A | 180 A | 2.5 V | 150 mA | 2250A, 2400A | 200 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
VS-T90RIA100SCR PHASE CONT 1000V 90A D-55 |
3,908 |
|
Datasheet |
- | D-55 T-Module | Bulk | Active | Single | 1 SCR | 1 kV | 90 A | 141 A | 2.5 V | 120 mA | 1780A, 1870A | 200 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
MCC95-14IO1BIPOLAR MODULE - THYRISTOR TO-2 |
8,996 |
|
Datasheet |
- | TO-240AA | Box | Active | Series Connection - All SCRs | 2 SCRs | 1.4 kV | 116 A | 182 A | 2.5 V | 150 mA | 2250A, 2430A | 200 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
MCMA110P1600TASCR MODULE 1.6KV 110A TO240AA |
8,638 |
|
Datasheet |
- | TO-240AA | Box | Active | Series Connection - All SCRs | 2 SCRs | 1.6 kV | 110 A | 170 A | 1.5 V | 150 mA | 1900A, 2050A | 200 mA | -40°C ~ 140°C (TJ) | - | - | Chassis Mount |
|
|
MCMA140P1200TASCR MODULE 1.2KV 140A TO240AA |
5,846 |
|
Datasheet |
- | TO-240AA | Box | Active | Series Connection - All SCRs | 2 SCRs | 1.2 kV | 140 A | 220 A | 1.5 V | 150 mA | 2400A, 2590A | 200 mA | -40°C ~ 140°C (TJ) | - | - | Chassis Mount |
|
VS-P405WSCR HY-BRIDGE 1200V 40A PACE-PAK |
8,294 |
|
Datasheet |
- | 8-PACE-PAK | Bulk | Active | Bridge, Single Phase - SCRs/Diodes (Layout 1) | 2 SCRs, 2 Diodes | 1.2 kV | - | - | 2 V | 60 mA | 385A, 400A | 130 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
MCC95-18IO1BMOD THYRISTOR DUAL 1800V TO240AA |
4,780 |
|
Datasheet |
- | TO-240AA | Box | Active | Series Connection - All SCRs | 2 SCRs | 1.8 kV | 116 A | 180 A | 2.5 V | 150 mA | 2250A, 2400A | 200 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
MCD94-22IO1BMOD THYRISTOR/DIO 2200V TO-240AA |
9,414 |
|
Datasheet |
- | TO-240AA | Box | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 2.2 kV | 104 A | 180 A | 1.5 V | 100 mA | 1700A, 1800A | 150 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
VS-VSKT105/16MODULE THY 1600V 105A ADD-A-PAK |
7,220 |
|
Datasheet |
- | ADD-A-PAK (3 + 4) | Bulk | Active | Series Connection - All SCRs | 2 SCRs | 1.6 kV | 105 A | 235 A | 2.5 V | 150 mA | 2000A, 2094A | 250 mA | -40°C ~ 130°C (TJ) | - | - | Chassis Mount |
|
|
VS-VSKT91/16MODULE THYRISTOR 95A ADD-A-PAK |
4,222 |
|
Datasheet |
- | ADD-A-PAK (3 + 4) | Bulk | Active | Series Connection - All SCRs | 2 SCRs | 1.6 kV | 95 A | 210 A | 2.5 V | 150 mA | 2000A, 2094A | 250 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
MCD162-08IO1MOD THYRISTOR/DIODE 800V Y4-M6 |
4,784 |
|
Datasheet |
- | Y4-M6 | Box | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 800 V | 190 A | 300 A | 2.5 V | 150 mA | 6000A, 6400A | 200 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
B512-2TMOD DIODE SCR 25A 240VAC .250"QC |
3,354 |
|
Datasheet |
B-2T | Module | Bulk | Active | Bridge, Single Phase - SCRs/Diodes (Layout 1) | 2 SCRs, 2 Diodes | 600 V | - | - | 2.5 V | 60 mA | 250A @ 60Hz | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
TD190N18SOFHPSA1SCR MODULE 1800V 275A MODULE |
6,756 |
|
Datasheet |
- | Module | Tray | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 1.8 kV | 190 A | 275 A | 2.5 V | 145 mA | 5200A @ 50Hz | 200 mA | -40°C ~ 125°C | - | - | Chassis Mount |
|
MCD132-16IO1MOD THYRISTOR/DIODE 1600V Y4-M6 |
5,760 |
|
Datasheet |
- | Y4 | Box | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 1.6 kV | 130 A | 300 A | 2.5 V | 150 mA | 4750A, 5080A | 200 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
MCC132-12IO1MOD THYRISTOR DUAL 1200V Y4-M6 |
8,930 |
|
Datasheet |
- | Y4-M6 | Box | Active | Series Connection - All SCRs | 2 SCRs | 1.2 kV | 130 A | 300 A | 2.5 V | 150 mA | 4750A, 5080A | 200 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
MCMA200PD1800YBDUAL THYRISTOR/DIODE Y4 |
4,072 |
|
Datasheet |
- | Module | Bulk | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 1.8 kV | 200 A | 315 A | 2.5 V | 150 mA | 6000A, 6480A | 200 mA | -40°C ~ 140°C (TJ) | - | - | Chassis Mount |
|
|
VS-VSKT162/12PBFMOD PH CTRL 1200V 160A INT-A-PAK |
5,008 |
|
Datasheet |
- | INT-A-PAK (3) | Bulk | Active | Series Connection - All SCRs | 2 SCRs | 1.2 kV | 160 A | 355 A | 2.5 V | 150 mA | 4870A, 5100A | 200 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
M252512FMODULE POWER 25A 600V SCR DIODE |
9,102 |
|
Datasheet |
- | Module | Bulk | Active | Bridge, Single Phase - SCRs/Diodes (Layout 1) | 2 SCRs, 2 Diodes | 600 V | - | - | 2.5 V | 50 mA | 300A @ 60Hz | 75 mA | - | - | - | Chassis Mount |
