SCRs - Modules
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Structure | Number of SCRs, Diodes | Voltage - Off State | Current - On State (It (AV)) (Max) | Current - On State (It (RMS)) (Max) | Voltage - Gate Trigger (Vgt) (Max) | Current - Gate Trigger (Igt) (Max) | Current - Non Rep. Surge 50, 60Hz (Itsm) | Current - Hold (Ih) (Max) | Operating Temperature | Grade | Qualification | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TT240N18SOFHPSA1LA-T-BOND MODULE |
7,182 |
|
Datasheet |
- | Module | Tray | Active | Series Connection - All SCRs | 2 SCRs | 1.8 kV | 240 A | 275 A | 2.5 V | 145 mA | 5200A @ 50Hz | 200 mA | 130°C (TC) | - | - | Chassis Mount |
|
MT160C16T2-BPMOD SCR DUAL 160A 1600V T2 |
2,280 |
|
Datasheet |
- | T2 | Tray | Active | Series Connection - All SCRs | 2 SCRs | 1.6 kV | 160 A | - | 3 V | 150 mA | 5400A @ 50Hz | 400 mA | -40°C ~ 130°C (TJ) | - | - | Chassis Mount |
|
B513F-2TMOD DIODE SCR 25A 280VAC .250"QC |
6,706 |
|
Datasheet |
B-2T | Module | Bulk | Active | Bridge, Single Phase - SCRs/Diodes (Layout 1) | 2 SCRs, 2 Diodes | 800 V | - | - | 2.5 V | 60 mA | 250A @ 60Hz | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
MT110C16T1-BPMOD SCR DUAL 110A 1600V T1 |
6,762 |
|
Datasheet |
- | T1 | Bulk | Active | Series Connection - All SCRs | 2 SCRs | 1.6 kV | 110 A | - | 3 V | 150 mA | 2250A @ 50Hz | 250 mA | -40°C ~ 130°C (TJ) | - | - | Chassis Mount |
|
MT200C16T2-BPMOD SCR DUAL 200A 1600V T2 |
5,542 |
|
Datasheet |
- | T2 | Bulk | Active | Series Connection - All SCRs | 2 SCRs | 1.6 kV | 200 A | - | 3 V | 200 mA | 5500A @ 50Hz | 400 mA | -40°C ~ 130°C (TJ) | - | - | Chassis Mount |
|
B512FSE-2T-YEBMOD DIODE SCR 25A 240VAC .250"QC |
2,454 |
|
Datasheet |
B-2T | Module | Bulk | Active | Bridge, Single Phase - SCRs/Diodes (Layout 1) | 2 SCRs, 2 Diodes | 600 V | - | - | 2.5 V | 60 mA | 250A @ 60Hz | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
VS-VSKT142/14PBFMODULE THYRISTOR 145A INT-A-PAK |
5,444 |
|
Datasheet |
- | INT-A-Pak | Bulk | Active | Series Connection - All SCRs | 2 SCRs | 1.4 kV | 140 A | 310 A | 2.5 V | 150 mA | 4500A, 4712A | 200 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
MT130CB16T2-BPMOD SCR/DIODE 130A 1600V T2 |
7,722 |
|
Datasheet |
- | T2 | Tray | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 1.6 kV | 130 A | - | 3 V | 150 mA | 4700A @ 50Hz | 400 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
TD390N18SOFHPSA1SCR MODULE 1.8KV 520A MODULE |
9,928 |
|
Datasheet |
- | Module | Tray | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 1.8 kV | 380 A | 520 A | 2 V | 150 mA | 9500A @ 50Hz | 150 mA | -40°C ~ 125°C (TC) | - | - | Chassis Mount |
|
T390N14TOFXPSA1SCR MODULE 1600V 600A DO200AA |
4,124 |
|
Datasheet |
- | TO-200AA | Tray | Active | Single | 1 SCR | 1.6 kV | 381 A | 600 A | 2 V | 150 mA | 4900A @ 50Hz | 200 mA | -40°C ~ 125°C | - | - | Chassis Mount |
|
|
T470N16TOFXPSA1SCR MODULE 1600V 800A DO200AA |
4,812 |
|
Datasheet |
- | TO-200AA | Tray | Active | Single | 1 SCR | 1.6 kV | 470 A | 800 A | 2 V | 200 mA | 7100A @ 50Hz | 300 mA | -40°C ~ 125°C | - | - | Chassis Mount |
|
|
TD390N16SOFHPSA1LA-T-BOND MODULE |
6,152 |
|
Datasheet |
- | Module | Tray | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 1.6 kV | 380 A | 520 A | 2 V | 150 mA | 9500A @ 50Hz | 150 mA | -40°C ~ 125°C (TC) | - | - | Chassis Mount |
|
TT390N16SOFHPSA1LA-T-BOND MODULE |
9,688 |
|
Datasheet |
- | Module | Tray | Active | Series Connection - All SCRs | 2 SCRs | 1.6 kV | 380 A | 520 A | 2 V | 150 mA | 9500A @ 50Hz | 150 mA | -40°C ~ 125°C (TC) | - | - | Chassis Mount |
|
|
T612FSMODULE POWER |
6,070 |
|
Datasheet |
- | Module | Bulk | Not For New Designs | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
T514FMODULE POWER |
2,482 |
|
Datasheet |
- | Module | Bulk | Not For New Designs | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
T420N16TOFXPSA1SCR MODULE 1800V 750A DO200AA |
4,936 |
|
Datasheet |
- | DO-200AA, A-PUK | Tray | Active | Single | 1 SCR | 1.8 kV | 424 A | 750 A | 2 V | 200 mA | 7200A @ 50Hz | 300 mA | -40°C ~ 125°C | - | - | Clamp On |
|
|
T640N16TOFXPSA1SCR MODULE 1800V 1250A DO200AA |
2,146 |
|
Datasheet |
- | DO-200AA, A-PUK | Tray | Active | Single | 1 SCR | 1.8 kV | 644 A | 1250 A | 2.2 V | 250 mA | 9400A @ 50Hz | 300 mA | -40°C ~ 125°C | - | - | Clamp On |
|
T640N14TOFXPSA1SCR MODULE 1800V 1250A DO200AA |
7,312 |
|
Datasheet |
- | DO-200AA, A-PUK | Tray | Active | Single | 1 SCR | 1.8 kV | 644 A | 1250 A | 2.2 V | 250 mA | 9400A @ 50Hz | 300 mA | -40°C ~ 125°C | - | - | Clamp On |
|
T940N16TOFXPSA1SCR MODULE 1800V 1759A DO200AB |
6,328 |
|
Datasheet |
- | DO-200AB, B-PUK | Tray | Active | Single | 1 SCR | 1.8 kV | 959 A | 1759 A | 2.2 V | 250 mA | 17500A @ 50Hz | 300 mA | -40°C ~ 125°C | - | - | Clamp On |
|
|
T720N16TOFXPSA1SCR MODULE 1800V 1500A DO200AB |
3,754 |
|
Datasheet |
- | DO-200AB, B-PUK | Tray | Active | Single | 1 SCR | 1.8 kV | 720 A | 1500 A | 1.5 V | 250 mA | 14500A @ 50Hz | 300 mA | -40°C ~ 125°C | - | - | Clamp On |
