TVS Diodes
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Type | Unidirectional Channels | Bidirectional Channels | Voltage - Reverse Standoff (Typ) | Voltage - Breakdown (Min) | Voltage - Clamping (Max) @ Ipp | Current - Peak Pulse (10/1000µs) | Power - Peak Pulse | Power Line Protection | Applications | Capacitance @ Frequency | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SMA6J28A R3GTVS DIODE 28VWM 44VC DO214AC |
2,346 |
|
Datasheet |
DO-214AC, SMA | SMA6J | Tape & Reel (TR) | Discontinued at Digi-Key | Zener | 1 | - | 28V | 31.1V | 44V | 13.6A | 600W | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Surface Mount | DO-214AC (SMA) |
|
SM30T6.8CAYTVS DIODE 5VWM 9.2VC SMC |
1,858 |
|
Datasheet |
DO-214AB, SMC | SM30TY, TRANSIL™ | Tape & Reel (TR) | Active | Zener | - | 1 | 5V | 6.45V | 9.2V | 327A | 3000W (3kW) | No | - | - | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC |
|
TPSMD10ATVS DIODE 10VWM 17VC DO214AB |
1,058 |
|
Datasheet |
DO-214AB, SMC | TPSMD | Tape & Reel (TR) | Active | Zener | 1 | - | 10V | 11.1V | 17V | 176.5A | 3000W (3kW) | No | - | - | -65°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | DO-214AB (SMCJ) |
|
3.0SMCJ54A-AU_R1_000A1SURFACE MOUNT TRANSIENT VOLTAGE |
1,400 |
|
Datasheet |
DO-214AB, SMC | - | Tape & Reel (TR) | Active | Zener | 1 | - | 54V | 60V | 87.1V | 34.4A | 3000W (3kW) | No | - | - | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | DO-214AB (SMC) |
|
1.5KE27AHE3_A/CTVS DIODE 23.1VWM 37.5VC 1.5KE |
1,222 |
|
Datasheet |
DO-201AA, DO-27, Axial | TransZorb® | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 23.1V | 25.7V | 37.5V | 40A | 1500W (1.5kW) | No | - | - | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Through Hole | 1.5KE |
|
MAX3205EETE+TVS DIODE 16TQFN |
12,000 |
|
Datasheet |
16-WFQFN Exposed Pad | - | Bulk | Obsolete | Steering (Rail to Rail) | 6 | - | - | - | - | - | - | Yes | General Purpose | - | -40°C ~ 125°C (TA) | - | - | Surface Mount | 16-TQFN (3x3) |
|
TPSMC130ATVS 1.5KW 130V 5%UNI DO-214AB |
12,000 |
|
Datasheet |
DO-214AB, SMC | TPSMC | Tape & Reel (TR) | Active | Zener | 1 | - | 111.15V | 123.5V | 179V | 8.5A | 1500W (1.5kW) | No | Telecom | - | -65°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC |
|
|
TPSMC220ATVS 1.5KW 220V 5%UNI DO-214AB |
12,000 |
|
Datasheet |
DO-214AB, SMC | TPSMC | Tape & Reel (TR) | Active | Zener | 1 | - | 188.1V | 209V | 328V | 4.6A | 1500W (1.5kW) | No | Telecom | - | -65°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC |
|
|
TPSMC180ATVS 1.5KW 180V 5%UNI DO-214AB |
11,668 |
|
Datasheet |
DO-214AB, SMC | TPSMC | Tape & Reel (TR) | Active | Zener | 1 | - | 153.9V | 171V | 246V | 6.2A | 1500W (1.5kW) | No | Telecom | - | -65°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC |
|
|
TPSMC160ATVS 1.5KW 160V 5%UNI DO-214AB |
11,660 |
|
Datasheet |
DO-214AB, SMC | TPSMC | Tape & Reel (TR) | Active | Zener | 1 | - | 136.8V | 152V | 219V | 6.9A | 1500W (1.5kW) | No | Telecom | - | -65°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC |
|
|
TPSMC120ATVS 1.5KW 120V 5%UNI DO-214AB |
10,266 |
|
Datasheet |
DO-214AB, SMC | TPSMC | Tape & Reel (TR) | Active | Zener | 1 | - | 102.6V | 114V | 165V | 9.2A | 1500W (1.5kW) | No | Telecom | - | -65°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC |
|
|
TPSMC200ATVS 1.5KW 200V 5%UNI DO-214AB |
9,848 |
|
Datasheet |
DO-214AB, SMC | TPSMC | Tape & Reel (TR) | Active | Zener | 1 | - | 171V | 190V | 274V | 5.5A | 1500W (1.5kW) | No | Telecom | - | -65°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC |
|
|
TPSMC150ATVS 1.5KW 150V 5%UNI DO-214AB |
9,646 |
|
Datasheet |
DO-214AB, SMC | TPSMC | Tape & Reel (TR) | Active | Zener | 1 | - | 128.25V | 142.5V | 207V | 7.3A | 1500W (1.5kW) | No | Telecom | - | -65°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC |
|
|
TPSMC250ATVS 1.5KW 250V 5%UNI DO-214AB |
7,878 |
|
Datasheet |
DO-214AB, SMC | TPSMC | Tape & Reel (TR) | Active | Zener | 1 | - | 213.75V | 237.5V | 344V | 4.4A | 1500W (1.5kW) | No | Telecom | - | -65°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC |
|
MAX3205EABL+TTVS DIODE 9UCSP |
15,790 |
|
Datasheet |
9-WFBGA, WLBGA | - | Tape & Reel (TR) | Obsolete | Steering (Rail to Rail) | 6 | - | - | - | - | - | - | Yes | General Purpose | - | -40°C ~ 125°C (TA) | - | - | Surface Mount | 9-WLP |
|
MSMBJ6.0ATVS DIODE 6VWM 10.3VC SMBJ |
1,106 |
|
Datasheet |
DO-214AA, SMB | - | Bulk | Active | Zener | 1 | - | 6V | 6.67V | 10.3V | 58.3A | 600W | No | General Purpose | - | -65°C ~ 150°C (TJ) | Military | MIL-PRF-19500 | Surface Mount | DO-214AA (SMBJ) |
|
3.0SMCJ6.0CA_R1_00001SURFACE MOUNT TRANSIENT VOLTAGE |
1,590 |
|
Datasheet |
DO-214AB, SMC | - | Tape & Reel (TR) | Active | Zener | - | 1 | 6V | 6.67V | 10.3V | 291.3A | 3000W (3kW) | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AB (SMC) |
|
PESD3USB3B/CXTVS DIODE 4VWM 3.7VC DSN0603-2 |
10,948 |
|
Datasheet |
15-UFBGA, WLCSP | PESDxUSB3B/C | Tape & Reel (TR) | Obsolete | Zener | - | 1 | 4V (Max) | 6V | - | 9.5A (8/20µs) | - | No | HDMI, USB | 0.29pF @ 1MHz | -40°C ~ 125°C (TA) | - | - | Surface Mount | 15-WLCSP (2.37x1.17) |
|
SMLJ6.5CA-TPTVS DIODE 6.5VWM 11.2VC DO214AB |
9,368 |
|
Datasheet |
DO-214AB, SMC | - | Tape & Reel (TR) | Active | Zener | - | 1 | 6.5V | 7.22V | 11.2V | 267.9A | 3000W (3kW) | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Surface Mount | DO-214AB (SMC) |
|
|
PESD3USB3S/CXTVS DIODE 15WLCSP |
8,760 |
|
Datasheet |
15-UFBGA, WLCSP | - | Tape & Reel (TR) | Obsolete | Zener | 2 | - | - | 6V | - | 8A (8/20µs) | - | No | HDMI, USB | 0.45pF @ 1MHz | -40°C ~ 85°C (TA) | - | - | Surface Mount | 15-WLCSP (2.37x1.17) |
