Surge Protection Devices (SPDs)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Form | Number of Poles | Voltage - Continuous Operating (Max) (MCOV) | Current - Discharge (Nom) (8/20µS) | Current - Discharge (Max) (8/20µS) | Operating Temperature | Voltage - Protection Rating (VPR) | Voltage - Protection Level (VP) (2416) | Operating Temperature | Features | Mounting Type | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1270-4S-277SPD TYPE 1/TYPE 2 350VAC MCOV |
9,784 |
|
Datasheet |
1270 | Box | Active | Type 1, Type 2 | Base + Module | 4 | 350VAC | 25 kA | 80 kA | 50 kA | - | 1.5 kV | -40°C ~ 85°C | Remote Signaling Contacts | DIN Rail | - |
|
|
2736280000SPD TYPE 2 75VAC MCOV 2 POLE |
10,378 |
|
Datasheet |
- | Box | Active | Type 2 | Base + Module | 2 | 75VAC | 20 kA | 50 kA | 200 kA | 330 V | - | -40°C ~ 85°C | - | DIN Rail | CE, cULus, VDE |
|
|
2801490SPD TYPE 2 350VAC MCOV 1 POLE |
18,540 |
|
Datasheet |
VAL-MS | Bulk | Active | Type 2 | Base + Module | 1 | 350VAC | 10 kA | 20 kA | - | - | 1.2 kV | -40°C ~ 80°C | - | DIN Rail | - |
|
|
AGDN48020RSPD TYPE 1 550VAC MCOV 2 POLE |
9,570 |
|
Datasheet |
- | Bulk | Active | Type 1 | Base + Module | 2 | 550VAC | 20 kA | - | 200 kA | 2 kV | - | -40°C ~ 85°C | Visual Life Indicator | DIN Rail | UL |
|
|
AGDN40020RSPD TYPE 1 480VAC MCOV 2 POLE |
4,226 |
|
Datasheet |
- | Bulk | Active | Type 1 | Base + Module | 2 | 480VAC | 20 kA | - | 200 kA | 1.5 kV | - | -40°C ~ 85°C | Visual Life Indicator | DIN Rail | UL |
|
|
2736320000SPD TYPE 2 300VAC MCOV 2 POLE |
4,424 |
|
Datasheet |
- | Box | Active | Type 2 | Base + Module | 2 | 300VAC | 20 kA | 50 kA | 200 kA | 900 V | - | -40°C ~ 85°C | - | DIN Rail | CE, cULus, VDE |
|
|
SPD2-350-MSPD TYP 1/TYP 2 350V MCOV 1 POLE |
5,446 |
|
Datasheet |
SPD2 1P+1 | Bulk | Active | Type 1, Type 2 | Module Only | 1 | 350V | 20 kA | 50 kA | 200 kA | 1 kV | 1.75 kV | -40°C ~ 80°C | Thermally Protected, Visual Life Indicator | DIN Rail | CE, cURus, UL, VDE |
|
|
2801041SPD TYPE 1/TYPE 2 335VAC MCOV |
9,956 |
|
Datasheet |
VAL-MS | Bulk | Active | Type 1, Type 2 | Base + Module | 1 | 335VAC | 12.5 kA | 50 kA | 25 kA | - | 1.6 kV | -40°C ~ 70°C | - | DIN Rail | EAC |
|
2801488SPD TYP2 75VAC/100VDC MCOV 1POLE |
8,786 |
|
Datasheet |
VAL-MS | Bulk | Active | Type 2 | Base + Module | 1 | 75VAC, 100VDC | 10 kA | 20 kA | - | - | 1.4 kV | -40°C ~ 70°C | - | DIN Rail | - |
|
|
SPD2-150-MSPD TYP 1/TYP 2 150V MCOV 1 POLE |
13,440 |
|
Datasheet |
SPD2 1P+1 | Bulk | Active | Type 1, Type 2 | Module Only | 1 | 150V | 20 kA | 50 kA | 200 kA | 600 V | 1.25 kV | -40°C ~ 80°C | Thermally Protected, Visual Life Indicator | DIN Rail | CE, cURus, UL, VDE |
|
|
BSPH31000YPVSPD TYPE 2/TYPE 4 1.17KVDC MCOV |
17,340 |
|
- |
BSPH | Bulk | Obsolete | Type 2, Type 4 | Base + Module | 3 | 1.17kVDC | 12.5 kA | 40 kA | - | 1 kV | 4 kV | -40°C ~ 80°C | - | DIN Rail | CE, UL |
|
|
BSPH2A24D24LVRSPD TYPE 3 30VAC MCOV 2 POLE |
10,374 |
|
Datasheet |
BSPH | Bulk | Active | Type 3 | Base + Module | 2 | 30VAC | 1 kA | 2 kA | 6 kA | - | 630 V | -40°C ~ 80°C | Remote Signaling Contacts | DIN Rail | CE, KEMA-KEUR |
|
1210-2S-400SPD TYPE 2/TYPE 4 420VAC MCOV |
11,854 |
|
Datasheet |
1210 | Bulk | Active | Type 2, Type 4 | Module Only | 2 | 420VAC | 20 kA | 100 kA | 100 kA | 1.2 kV | 1.8 kV | -50°C ~ 85°C | Remote Signaling Contacts, Thermally Protected | DIN Rail | CE, CSA, UL |
|
|
SPD2-PV11-3P0SPD TYP 1/TYP 2 1.1KV MCOV 3POLE |
8,152 |
|
Datasheet |
SPD2 PV | Bulk | Active | Type 1, Type 2 | Base + Module | 3 | 1.1kV | 20 kA | 40 kA | 50 kA | 3 kV | 4.2 kV | -40°C ~ 80°C | Thermally Protected, Visual Life Indicator | DIN Rail | CE, cURus, UL, VDE |
|
|
1270-4S-690SPD TYPE 1/TYPE 2 750VAC MCOV |
17,192 |
|
Datasheet |
1270 | Box | Active | Type 1, Type 2 | Base + Module | 4 | 750VAC | 25 kA | 65 kA | 50 kA | - | 2.8 kV | -40°C ~ 85°C | Remote Signaling Contacts | DIN Rail | - |
|
|
1270-4NS-127SPD TYPE 1/TYPE 2 180VAC MCOV |
9,510 |
|
Datasheet |
1270 | Box | Active | Type 1, Type 2 | Base + Module | 4 | 180VAC | 50 kA | 100 kA | 50 kA | - | 1.5 kV | -40°C ~ 85°C | Remote Signaling Contacts | DIN Rail | - |
|
|
1270-4NS-277SPD TYPE 1/TYPE 2 350VAC MCOV |
7,974 |
|
Datasheet |
1270 | Box | Active | Type 1, Type 2 | Base + Module | 4 | 350VAC | 50 kA | 100 kA | 50 kA | - | 1.5 kV | -40°C ~ 85°C | Remote Signaling Contacts | DIN Rail | - |
|
|
1270-4NS-120SPD TYPE 1/TYPE 2 150VAC MCOV |
7,344 |
|
Datasheet |
1270 | Box | Active | Type 1, Type 2 | Base + Module | 4 | 150VAC | 50 kA | 100 kA | 50 kA | - | 1.5 kV | -40°C ~ 85°C | Remote Signaling Contacts | DIN Rail | - |
|
|
SPP40SP3480DLGSPD TYPE 1 |
8,796 |
|
Datasheet |
* | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
BSPH2A48D48LVRSPD TYPE 3 60VAC MCOV 2 POLE |
17,952 |
|
Datasheet |
BSPH | Bulk | Active | Type 3 | Base + Module | 2 | 60VAC | 1 kA | 2 kA | 6 kA | - | 730 V | -40°C ~ 80°C | Remote Signaling Contacts | DIN Rail | CE, KEMA-KEUR |
