Signal Relays, Up to 2 Amps
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Mounting Type | Coil Voltage | Contact Form | Contact Rating (Current) | Switching Voltage | Load - Max Switching | Coil Current | Coil Type | Features | Termination Style | Seal Rating | Coil Insulation | Must Operate Voltage | Must Release Voltage | Operate Time | Release Time | Operating Temperature | Contact Material | Relay Type | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
3SBM1071A2RELAY GEN PURPOSE 4PDT 2A 26.5V |
6,864 |
|
Datasheet |
3SBM, CII | Bulk | Active | Through Hole | 26.5VDC | 4PDT (4 Form C) | 2 A | 28VDC - Nom | - | 27.2 mA | Latching, Dual Coil | - | PC Pin | - | - | 13.5 VDC | - | 4 ms | - | -65°C ~ 125°C | - | General Purpose | Military | MIL-R-39016/31 |
|
3SAM1821A2RELAY GEN PURPOSE DPDT 2A 26.5V |
4,494 |
|
Datasheet |
3SAM, CII | Bulk | Active | Chassis Mount | 26.5VDC | DPDT (2 Form C) | 2 A | 115VAC, 28VDC - Nom | - | 27.2 mA | Latching, Dual Coil | - | Solder Hook | Sealed - Hermetically | - | - | - | 4 ms | 2 ms | -65°C ~ 125°C | - | General Purpose | - | - |
|
|
1-1617086-4RELAY GEN PURPOSE 4PDT 2A 26.5V |
7,886 |
|
Datasheet |
3SBM, CII | Bulk | Active | Through Hole | 26.5VDC | 4PDT (4 Form C) | 2 A | - | - | 27.2 mA | Non Latching | - | PC Pin | - | - | 13.5 VDC | - | 4 ms | 4 ms | -65°C ~ 125°C | - | General Purpose | Military | MIL-R-39016/31 |
|
|
2-1617088-0RELAY GEN PURPOSE DPDT 2A 26.5V |
7,942 |
|
Datasheet |
3SAM, CII | Bulk | Active | Chassis Mount | 26.5VDC | DPDT (2 Form C) | 2 A | 115VAC, 28VDC - Nom | - | 27.2 mA | Latching, Dual Coil | - | PC Pin | Sealed - Hermetically | - | - | - | 4 ms | 2 ms | -65°C ~ 125°C | - | General Purpose | - | - |
|
|
1-1617577-2RELAY |
6,054 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
3SAM1865A2RELAY GEN PURPOSE DPDT 2A 26.5V |
4,450 |
|
- |
3SAM, CII | Bulk | Active | Chassis Mount | 26.5VDC | DPDT (2 Form C) | 2 A | 115VAC, 28VDC - Nom | - | 27.2 mA | Latching, Dual Coil | - | Solder Hook | Sealed - Hermetically | - | - | - | 4 ms | 2 ms | -65°C ~ 125°C | - | General Purpose | - | - |
|
|
1617522-2RELAY GENERAL PURPOSE DPDT 2A |
2,082 |
|
- |
3SAF | Bulk | Active | Chassis Mount | - | DPDT (2 Form C) | 2 A | 115VAC, 28VDC - Max | 230VA, 56W | - | Non Latching | - | Solder Hook | - | - | - | - | - | - | - | - | General Purpose | - | - |
|
1617016-4RELAY |
3,068 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
1-1617522-2RELAY GEN PURPOSE DPDT 2A 26.5V |
7,088 |
|
Datasheet |
3SAM, CII | Bulk | Active | Chassis Mount | 26.5VDC | DPDT (2 Form C) | 2 A | 115VAC, 28VDC - Nom | - | 27.2 mA | Latching, Dual Coil | - | PC Pin | Sealed - Hermetically | - | - | - | 4 ms | 2 ms | -65°C ~ 125°C | - | General Purpose | - | - |
|
|
1617088-5RELAY GENERAL PURPOSE DPDT 2A |
8,242 |
|
Datasheet |
3SAM, CII | Bulk | Active | - | - | DPDT (2 Form C) | 2 A | 115VAC, 28VDC - Nom | - | - | Non Latching | - | - | - | - | - | - | 4 ms | 4 ms | -65°C ~ 125°C | - | General Purpose | - | - |
|
|
SR-7606RELAY GENERAL PURPOSE 4PDT 2A 6V |
9,944 |
|
Datasheet |
SR, CII | Bulk | Active | Chassis Mount | 6VDC | 4PDT (4 Form C) | 2 A | 28VDC - Nom | - | 240 mA | Non Latching | - | Solder Hook | - | - | 3.2 VDC | - | 7 ms | 7 ms | -65°C ~ 125°C | - | General Purpose | Military | MIL-R-39016/40 |
|
|
5-1617563-7RELAY GENERAL PURPOSE 4PDT 2A |
6,998 |
|
Datasheet |
SR, CII | Bulk | Active | - | - | 4PDT (4 Form C) | 2 A | - | - | - | - | - | - | Sealed - Hermetically | - | - | - | 5 ms | 5 ms | -65°C ~ 125°C | - | General Purpose | - | - |
|
|
SR-7601RELAY GEN PURPOSE 4PDT 2A 26.5V |
3,158 |
|
Datasheet |
SR, CII | Bulk | Active | Chassis Mount | 26.5VDC | 4PDT (4 Form C) | 2 A | 28VDC - Nom | - | 68 mA | Non Latching | - | Solder Hook | - | - | 14 VDC | 1.4 VDC | 7 ms | 7 ms | -65°C ~ 125°C | - | General Purpose | Military | MIL-R-39016/40 |
|
|
4-1617522-3RELAY GENERAL PURPOSE DPDT 2A 4V |
8,798 |
|
Datasheet |
3SAT, CII | Bulk | Active | Chassis Mount | 4VDC | DPDT (2 Form C) | 2 A | 115VAC, 28VDC - Max | 230VA, 56W | 40 mA | Non Latching | - | PC Pin | Sealed - Hermetically | - | - | - | 15 ms | 10 ms | -65°C ~ 125°C | - | General Purpose | - | - |
|
|
2-1617514-9RELAY GEN PURPOSE DPDT 2A 18V |
8,518 |
|
Datasheet |
3SAT, CII | Bulk | Active | Chassis Mount | 18VDC | DPDT (2 Form C) | 2 A | 115VAC, 28VDC - Max | 230VA, 56W | 9 mA | Non Latching | - | Solder Hook | Sealed - Hermetically | - | - | - | 15 ms | 10 ms | -65°C ~ 125°C | - | General Purpose | - | - |
|
|
3-1617514-4RELAY GEN PURPOSE DPDT 2A 1.8V |
6,194 |
|
Datasheet |
3SAT, CII | Bulk | Active | Chassis Mount | 1.8VDC | DPDT (2 Form C) | 2 A | 115VAC, 28VDC - Max | 230VA, 56W | 90 mA | Non Latching | - | Solder Hook | Sealed - Hermetically | - | - | - | 15 ms | 10 ms | -65°C ~ 125°C | - | General Purpose | - | - |
|
|
3-1617514-6RELAY GENERAL PURPOSE DPDT 2A 9V |
3,418 |
|
Datasheet |
3SAT, CII | Bulk | Active | Chassis Mount | 9VDC | DPDT (2 Form C) | 2 A | 115VAC, 28VDC - Max | 230VA, 56W | 18 mA | Non Latching | - | Solder Hook | Sealed - Hermetically | - | - | - | 15 ms | 10 ms | -65°C ~ 125°C | - | General Purpose | - | - |
|
|
4-1617514-7RELAY GEN PURPOSE DPDT 2A 16.5V |
4,510 |
|
Datasheet |
3SAT, CII | Bulk | Active | Chassis Mount | 16.5VDC | DPDT (2 Form C) | 2 A | 115VAC, 28VDC - Max | 230VA, 56W | 11 mA | Non Latching | - | Solder Hook | Sealed - Hermetically | - | - | - | 15 ms | 10 ms | -65°C ~ 125°C | - | General Purpose | - | - |
|
|
3SAT1324A2RELAY GEN PURPOSE DPDT 2A 13V |
2,292 |
|
Datasheet |
3SAT, CII | Bulk | Active | Chassis Mount | 13VDC | DPDT (2 Form C) | 2 A | 115VAC, 28VDC - Max | 230VA, 56W | 13 mA | Non Latching | - | Solder Hook | Sealed - Hermetically | - | - | - | 15 ms | 10 ms | -65°C ~ 125°C | - | General Purpose | - | - |
|
|
2-1617514-2RELAY GEN PURPOSE DPDT 2A 26.5V |
3,934 |
|
Datasheet |
3SAT, CII | Bulk | Active | Chassis Mount | 26.5VDC | DPDT (2 Form C) | 2 A | 115VAC, 28VDC - Max | 230VA, 56W | 6 mA | Non Latching | - | PC Pin | Sealed - Hermetically | - | - | - | 15 ms | 10 ms | -65°C ~ 125°C | - | General Purpose | - | - |
