Power Distribution Switches, Load Drivers
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Switch Type | Number of Outputs | Ratio - Input:Output | Output Configuration | Output Type | Interface | Voltage - Load | Voltage - Supply (Vcc/Vdd) | Current - Output (Max) | Rds On (Typ) | Input Type | Features | Fault Protection | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AUIPS6011IC PWR SWITCH N-CHAN 1:1 TO220 |
7,788 |
|
Datasheet |
TO-220-5 | - | Tube | Obsolete | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 36V (Max) | Not Required | 18A | 11mOhm | Non-Inverting | Auto Restart | Current Limiting (Fixed), Open Load Detect, Over Temperature | -40°C ~ 150°C (TJ) | Automotive | AEC-Q100 | Through Hole | TO-220 |
|
AUIPS6011RIC PWR SWITCH N-CHANNEL 1:1 DPAK |
7,128 |
|
Datasheet |
TO-252-3, DPAK (2 Leads + Tab), SC-63 | - | Tube | Obsolete | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 36V (Max) | Not Required | 5.6A | 11mOhm | Non-Inverting | Auto Restart | Current Limiting (Fixed), Open Load Detect, Over Temperature | -40°C ~ 150°C (TJ) | Automotive | AEC-Q100 | Surface Mount | TO-252AA (DPAK) |
|
|
AUIPS6011SIC PWR SWITCH N-CHAN 1:1 D2PAK |
2,274 |
|
Datasheet |
TO-263-5, D2PAK (4 Leads + Tab), TO-263BB | - | Tube | Obsolete | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 36V (Max) | Not Required | 6.3A | 11mOhm | Non-Inverting | Auto Restart | Current Limiting (Fixed), Open Load Detect, Over Temperature | -40°C ~ 150°C (TJ) | Automotive | AEC-Q100 | Surface Mount | D2PAK |
|
AUIPS6021IC PWR SWITCH N-CHAN 1:1 TO220 |
3,992 |
|
Datasheet |
TO-220-5 | - | Tube | Obsolete | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 36V (Max) | Not Required | 12A | 24mOhm | Non-Inverting | Auto Restart | Current Limiting (Fixed), Open Load Detect, Over Temperature | -40°C ~ 150°C (TJ) | Automotive | AEC-Q100 | Through Hole | TO-220 |
|
AUIPS6021RIC PWR SWITCH N-CHANNEL 1:1 DPAK |
3,132 |
|
Datasheet |
TO-252-3, DPAK (2 Leads + Tab), SC-63 | - | Tube | Obsolete | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 36V (Max) | Not Required | 3.9A | 24mOhm | Non-Inverting | Auto Restart | Current Limiting (Fixed), Open Load Detect, Over Temperature | -40°C ~ 150°C (TJ) | Automotive | AEC-Q100 | Surface Mount | TO-252AA (DPAK) |
.jpg)
|
AUIPS6021SIC PWR SWITCH N-CHAN 1:1 D2PAK |
9,690 |
|
Datasheet |
TO-263-5, D2PAK (4 Leads + Tab), TO-263BB | - | Tube | Obsolete | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 36V (Max) | Not Required | 4.3A | 24mOhm | Non-Inverting | Auto Restart | Current Limiting (Fixed), Open Load Detect, Over Temperature | -40°C ~ 150°C (TJ) | Automotive | AEC-Q100 | Surface Mount | D2PAK |
|
|
AUIPS6031IC PWR SWITCH N-CHAN 1:1 TO220 |
5,056 |
|
Datasheet |
TO-220-5 | - | Tube | Obsolete | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 36V (Max) | Not Required | 8.9A | 46mOhm | Non-Inverting | Auto Restart | Current Limiting (Fixed), Open Load Detect, Over Temperature | -40°C ~ 150°C (TJ) | Automotive | AEC-Q100 | Through Hole | TO-220 |
|
|
AUIPS6031RIC PWR SWITCH N-CHANNEL 1:1 DPAK |
2,210 |
|
Datasheet |
TO-252-3, DPAK (2 Leads + Tab), SC-63 | - | Tube | Obsolete | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 36V (Max) | Not Required | 2.8A | 46mOhm | Non-Inverting | Auto Restart | Current Limiting (Fixed), Open Load Detect, Over Temperature | -40°C ~ 150°C (TJ) | Automotive | AEC-Q100 | Surface Mount | TO-252AA (DPAK) |
|
AUIPS6031SIC PWR SWITCH N-CHAN 1:1 D2PAK |
9,882 |
|
Datasheet |
TO-263-5, D2PAK (4 Leads + Tab), TO-263BB | - | Tube | Obsolete | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 36V (Max) | Not Required | 3.1A | 46mOhm | Non-Inverting | Auto Restart | Current Limiting (Fixed), Open Load Detect, Over Temperature | -40°C ~ 150°C (TJ) | Automotive | AEC-Q100 | Surface Mount | D2PAK |
|
|
AUIPS6041IC PWR SWITCH N-CHAN 1:1 TO220-5 |
8,784 |
|
Datasheet |
TO-220-5 | - | Tube | Obsolete | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 6V ~ 28V | Not Required | - | 110mOhm | Non-Inverting | Auto Restart | Current Limiting (Fixed), Open Load Detect, Over Temperature | -40°C ~ 150°C (TJ) | Automotive | AEC-Q100 | Through Hole | TO-220-5 |
|
AUIPS6041GIC PWR SWITCH N-CHAN 1:1 8SOIC |
4,272 |
|
Datasheet |
8-SOIC (0.154", 3.90mm Width) | - | Tube | Obsolete | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 6V ~ 28V | Not Required | 1.6A | 110mOhm | Non-Inverting | Auto Restart | Current Limiting (Fixed), Open Load Detect, Over Temperature | -40°C ~ 150°C (TJ) | Automotive | AEC-Q100 | Surface Mount | 8-SOIC |
|
|
AUIPS6041RIC PWR SWITCH N-CHAN 1:1 DPAK-5 |
9,014 |
|
Datasheet |
TO-252-5, DPAK (4 Leads + Tab), TO-252AD | - | Tube | Obsolete | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 6V ~ 28V | Not Required | 2.3A | 110mOhm | Non-Inverting | Auto Restart | Current Limiting (Fixed), Open Load Detect, Over Temperature | -40°C ~ 150°C (TJ) | Automotive | AEC-Q100 | Surface Mount | DPAK-5 |
|
|
AUIPS6041SIC PWR SWITCH N-CHAN 1:1 D2PAK-5 |
6,252 |
|
Datasheet |
TO-252-5, DPAK (4 Leads + Tab), TO-252AD | - | Tube | Obsolete | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 6V ~ 28V | Not Required | - | 110mOhm | Non-Inverting | Auto Restart | Current Limiting (Fixed), Open Load Detect, Over Temperature | -40°C ~ 150°C (TJ) | Automotive | AEC-Q100 | Surface Mount | D2PAK-5 |
|
|
AUIPS7125RIC PWR SWITCH N-CHAN 1:1 TO252-5 |
2,220 |
|
Datasheet |
TO-252-5, DPAK (4 Leads + Tab), TO-252AD | - | Tube | Obsolete | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 60V (Max) | Not Required | 3.8A | 24mOhm | Non-Inverting | - | Current Limiting (Fixed), Over Temperature | -40°C ~ 150°C (TJ) | Automotive | AEC-Q100 | Surface Mount | PG-TO252-5 |
|
AUIPS7142GIC PWR SWITCH N-CHAN 1:1 16SOIC |
6,342 |
|
Datasheet |
16-SOIC (0.295", 7.50mm Width) | - | Tube | Obsolete | General Purpose | 2 | 1:1 | High Side | N-Channel | On/Off | 60V (Max) | Not Required | 1.5A | 75mOhm | Non-Inverting | - | Current Limiting (Fixed), Over Temperature | -40°C ~ 150°C (TJ) | Automotive | AEC-Q100 | Surface Mount | PG-DSO-16-15 |
|
AUIPS72211RIC PWR SWITCH N-CHAN 1:1 DPAK-5 |
7,054 |
|
Datasheet |
TO-252-5, DPAK (4 Leads + Tab), TO-252AD | - | Tube | Obsolete | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 6V ~ 60V | - | - | 30mOhm | Non-Inverting | - | Current Limiting (Fixed), Over Temperature | -40°C ~ 150°C (TJ) | Automotive | AEC-Q100 | Surface Mount | PG-TO252-5 |
.jpg)
|
VN5E050ASOTR-EIC PWR DRIVER N-CHANNEL 1:1 16SO |
6,246 |
|
Datasheet |
16-SOIC (0.295", 7.50mm Width) | VIPower™ | Tape & Reel (TR) | Active | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 4.5V ~ 28V | Not Required | 19A | 50mOhm | Non-Inverting | Auto Restart | Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage | -40°C ~ 150°C (TJ) | - | - | Surface Mount | 16-SO |
|
|
VND5E050ASOTR-EIC PWR DRIVER N-CHANNEL 1:1 16SO |
8,068 |
|
Datasheet |
16-SOIC (0.295", 7.50mm Width) | VIPower™ | Tape & Reel (TR) | Active | General Purpose | 2 | 1:1 | High Side | N-Channel | On/Off | 4.5V ~ 28V | Not Required | 19A | 50mOhm | Non-Inverting | Auto Restart | Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage | -40°C ~ 150°C (TJ) | - | - | Surface Mount | 16-SO |
|
|
VND5E160ASOTR-EIC PWR DRIVER N-CHANNEL 1:1 16SO |
3,604 |
|
Datasheet |
16-SOIC (0.295", 7.50mm Width) | VIPower™ | Tape & Reel (TR) | Active | General Purpose | 2 | 1:1 | High Side | N-Channel | On/Off | 4.5V ~ 28V | Not Required | 7A | 160mOhm | Non-Inverting | Auto Restart | Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage | -40°C ~ 150°C (TJ) | - | - | Surface Mount | 16-SO |
|
MAX890LESA/V+IC PWR SWITCH P-CHAN 1:1 8SOIC |
7,820 |
|
- |
8-SOIC (0.154", 3.90mm Width) | - | Tube | Obsolete | General Purpose | 1 | 1:1 | High Side | P-Channel | On/Off | 2.7V ~ 5.5V | Not Required | 1.2A | 75mOhm | Non-Inverting | Status Flag | Current Limiting (Adjustable), Over Temperature | -40°C ~ 85°C (TA) | Automotive | AEC-Q100 | Surface Mount | 8-SOIC |
