Power Line Filter Modules
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Filter Type | Configuration | Voltage - Rated DC | Voltage - Rated AC | Voltage - Rated AC (Phase to Ground/Neutral) | Voltage - Rated AC (Phase to Phase) | Current | Frequency - Operating | Applications | Approval Agency | Operating Temperature | Mounting Type | Termination Style | Inductance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
STFE200-24LLINE FILTER 240VAC 20A DIN RAIL |
2,252 |
|
Datasheet |
STFE | Bulk | Active | Single Phase | Single Stage | - | 240V | - | - | 20 A | 47Hz, 63Hz | General Purpose | CE, cURus | -40°C ~ 50°C | DIN Rail | Terminal Block | - |
|
FN2200-1500-99LINE FILTER 1200VDC 1.5KA CHASS |
3,916 |
|
Datasheet |
FN 2200 | Box | Active | DC | Single Stage | 1200V (1.2kV) | - | - | - | 1.5 kA | - | Photovoltaic Inverter | cURus, ENEC | -40°C ~ 100°C | Chassis Mount | Terminal Post | - |
|
FN351H-180-36LINE FILTER 180A CHASSIS MOUNT |
7,430 |
|
Datasheet |
FN 351 | Tray | Active | Three Phase (Delta) | Single Stage | - | - | 300 V | 520 V | 180 A | DC ~ 60Hz | Inverters, Power Drive Systems | - | -25°C ~ 100°C | Chassis Mount | Terminal Block | - |
|
FN2210-2300-99-R5LINE FILTER 1000VDC 2.3KA CHASS |
4,492 |
|
Datasheet |
FN 2210 | Box | Active | DC | Single Stage | 1000V (1kV) | - | - | - | 2.3 kA | DC | Inverters, Power Drive Systems | CE, cURus | -40°C ~ 100°C | Chassis Mount | Terminal Post | - |
|
FMAC-0955-H212ILINE FILTER 480/520VAC 180A CHAS |
5,708 |
|
Datasheet |
FMAC | Bulk | Active | Three Phase (Delta) | Single Stage | - | 480V, 520V | - | - | 180 A | 50/60Hz | Photovoltaic Inverter | cURus, ENEC, VDE | -25°C ~ 100°C | Chassis Mount | Terminal Block | 400µH |
|
FMAD-0955-H210LINE FILTER 277/480VAC 180A CHAS |
7,402 |
|
Datasheet |
FMAD | Bulk | Active | Three Phase (Wye) | Single Stage | - | 277V, 480V | - | - | 180 A | 50/60Hz | General Purpose | cURus, VDE | -25°C ~ 100°C | Chassis Mount | Terminal Block | 250µH |
|
FMAC-0956-H310LINE FILTER 480/520VAC 250A CHAS |
5,064 |
|
Datasheet |
FMAC | Bulk | Active | Three Phase (Delta) | Single Stage | - | 480V, 520V | - | - | 250 A | 50/60Hz | Photovoltaic Inverter | cURus, ENEC, VDE | -25°C ~ 100°C | Chassis Mount | Terminal Block | 300µH |
|
FMAD-0956-H310LINE FILTER 277/480VAC 250A CHAS |
6,194 |
|
Datasheet |
FMAD | Bag | Active | Three Phase (Wye) | Single Stage | - | 277V, 480V | - | - | 250 A | 50/60Hz | General Purpose | cURus, VDE | -25°C ~ 100°C | Chassis Mount | Terminal Block | 200µH |
|
|
FN2200B-2300-99LINE FILTER 1200VDC 2.3KA CHASS |
9,702 |
|
Datasheet |
FN 2200 | Box | Active | DC | Single Stage | 1200V (1.2kV) | - | - | - | 2.3 kA | DC | Photovoltaic Inverter | cURus, ENEC, UKCA | -40°C ~ 100°C | Chassis Mount | Terminal Post | - |
|
FN3359-1000-99LINE FILTER 1KA CHASSIS MOUNT |
4,720 |
|
Datasheet |
FN 3359 | Tray | Active | Three Phase (Delta) | Three Stage | - | - | 300 V | 520 V | 1 kA | DC ~ 60Hz | General Purpose | cURus, ENEC | -25°C ~ 100°C | Chassis Mount | Terminal Post | - |
|
FN3359HV-1600-99LINE FILTER 1.6KA CHASSIS MOUNT |
7,392 |
|
Datasheet |
FN 3359 | Tray | Active | Three Phase (Delta) | Three Stage | - | - | 400 V | 690 V | 1.6 kA | DC ~ 60Hz | General Purpose | cURus, ENEC | -25°C ~ 100°C | Chassis Mount | Terminal Post | - |
|
5500.2640.01LINE FILTER 125V/250VAC 1A CHASS |
8,496 |
|
Datasheet |
FMAB NEO | Box | Active | Single Phase | Single Stage | - | 125V, 250V | - | - | 1 A | 50/60Hz | General Purpose | cURus, ENEC, VDE | -40°C ~ 100°C | Chassis Mount | Quick Connect | - |
|
FN402B-1-02LINE FILTER 250VAC 1A TH |
2,968 |
|
Datasheet |
FN 402 | Tray | Active | Single Phase | Single Stage | - | 250V | - | - | 1 A | DC ~ 400Hz | General Purpose | CSA, ENEC, UR | -25°C ~ 100°C | Through Hole | PC Pins | 10mH |
|
5500.2651.04LINE FILTER 125V/250VAC 3A CHASS |
7,638 |
|
Datasheet |
FMAB NEO | Box | Active | Single Phase | Single Stage | - | 125V, 250V | - | - | 3 A | 50/60Hz | Medical | cURus, ENEC, VDE | -40°C ~ 100°C | Chassis Mount | Quick Connect | - |
|
5500.2641.01LINE FILTER 125V/250VAC 3A CHASS |
6,808 |
|
Datasheet |
FMAB NEO | Box | Active | Single Phase | Single Stage | - | 125V, 250V | - | - | 3 A | 50/60Hz | General Purpose | cURus, ENEC, VDE | -40°C ~ 100°C | Chassis Mount | Quick Connect | - |
|
|
10IHE1LINE FLTR 120/250VAC 10A PANEL |
6,566 |
|
Datasheet |
IH, Corcom | Bulk | Active | Single Phase | Single Stage | - | 120V, 250V | 4000 V | 1500 V | 10 A | 50Hz ~ 60Hz | Medical | CSA, UL, VDE | -10°C ~ 40°C | Panel Mount | Quick Connect | - |
|
5500.2079LINE FILTER 125V/250VAC 4A CHASS |
8,778 |
|
Datasheet |
FMLB-41 | Bulk | Active | Single Phase | Single Stage | - | 125V, 250V | - | - | 4 A | 50/60Hz | Medical | cURus, ENEC, VDE | -25°C ~ 100°C | Chassis Mount | Quick Connect | 1.5mH |
|
5500.2100LINE FILTER 125V/250VAC 6A CHASS |
6,866 |
|
Datasheet |
FMW-41 | Bulk | Active | Single Phase | Single Stage | - | 125V, 250V | - | - | 6 A | 50/60Hz | General Purpose | cURus, ENEC, VDE | -25°C ~ 100°C | Chassis Mount | Quick Connect | 800µH |
|
5500.2631.04LINE FILTER 125V/250VAC 3A CHASS |
4,188 |
|
Datasheet |
FMAB NEO | Box | Active | Single Phase | Single Stage | - | 125V, 250V | - | - | 3 A | 50/60Hz | Medical | cURus, ENEC, VDE | -40°C ~ 100°C | Chassis Mount | Quick Connect | - |
|
|
10EK3LINE FILTER 250VAC 10A CHASS MNT |
7,152 |
|
Datasheet |
K | Bulk | Active | Single Phase | Single Stage | - | 250V | - | - | 10 A | 50/60Hz | General Purpose | CSA, UR, VDE | -10°C ~ 40°C | Chassis Mount | Wire Leads | 495µH |
