Gates and Inverters - Multi-Function, Configurable
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Logic Type | Number of Circuits | Number of Inputs | Schmitt Trigger Input | Output Type | Current - Output High, Low | Voltage - Supply | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SY55851AUKIIC GATE UNIV 3GHZ 50 OHM 10MSOP |
8,812 |
|
Datasheet |
SY55 | 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) | Tube | Discontinued at Digi-Key | Configurable Multiple Function | 1 | 2 | No | Differential | - | 2.3V ~ 3.6V | -40°C ~ 85°C | - | - | Surface Mount | 10-MSOP |
|
SY10EP05VZGIC GATE AND/NAND 2INP DIFF 8SOIC |
9,536 |
|
Datasheet |
10EP | 8-SOIC (0.154", 3.90mm Width) | Tube | Active | AND/NAND Gate | 1 | 2 Input (1, 1) | No | Differential | - | 3V ~ 5.5V | -40°C ~ 85°C | - | - | Surface Mount | 8-SOIC |
.jpg)
|
MC10E101FNR2IC GATE OR/NOR QUAD 4INP 28-PLCC |
3,248 |
|
- |
10E | 28-LCC (J-Lead) | Tape & Reel (TR) | Obsolete | NOR/OR Gate | 4 | 16 Input (4, 4, 4, 4) | No | Differential | - | 4.2V ~ 5.7V | -40°C ~ 85°C | - | - | Surface Mount | 28-PLCC (11.51x11.51) |
|
|
MC10E104FNIC GATE AND/NAND QD 2INP 28-PLCC |
9,630 |
|
- |
10E | 28-LCC (J-Lead) | Tube | Obsolete | AND/NAND Gate | 5 | 10 Input (2, 2, 2, 2, 2) | No | Differential | - | 4.2V ~ 5.7V | -40°C ~ 85°C | - | - | Surface Mount | 28-PLCC (11.51x11.51) |
|
SY58051UMIIC GATE CML UNIV I/O TERM 16MLF |
4,404 |
|
Datasheet |
SY55 | 16-VFQFN Exposed Pad | Tray | Obsolete | Configurable Multiple Function | 1 | 2 | No | Differential | - | 2.3V ~ 3.6V | -40°C ~ 85°C | - | - | Surface Mount | 16-MLF® (3x3) |
|
|
SY58051UMGIC GATE CML UNIV I/O TERM 16MLF |
7,138 |
|
Datasheet |
SY58 | 16-VFQFN Exposed Pad | Tray | Obsolete | Configurable Multiple Function | 1 | 2 | No | Differential | - | 2.3V ~ 3.6V | -40°C ~ 85°C | - | - | Surface Mount | 16-MLF® (3x3) |
|
SY100S302FCIC GATE OR/NOR QUINT 2IN 24-CPAK |
4,472 |
|
- |
100S | 24-CQFlatPack, CerPack | Bulk | Discontinued at Digi-Key | NOR/OR Gate | 5 | 10 Input (2, 2, 2, 2, 2) | No | Differential | - | 4.2V ~ 5.5V | 0°C ~ 85°C | - | - | Surface Mount | 24-CerPack |
|
SY100S307JY-TRIC GATE OR/NOR 28PLCC |
6,950 |
|
Datasheet |
100S | 28-LCC (J-Lead) | Tape & Reel (TR) | Obsolete | NOR/OR Gate | 5 | 10 Input (2, 2, 2, 2, 2) | No | Differential | - | -4.2V ~ -5.5V | -40°C ~ 85°C | - | - | Surface Mount | 28-PLCC (11.5x11.5) |
|
NB7L86MMNR2IC GATE MULTI FUNCT DIFF 16-QFN |
3,334 |
|
- |
- | 16-VFQFN Exposed Pad | Tape & Reel (TR) | Obsolete | Configurable Multiple Function | 2 | 2 | No | Differential | - | 2.4V ~ 3.5V | -40°C ~ 85°C | - | - | Surface Mount | 16-QFN (3x3) |
|
|
NB7L86MMNIC GATE MULTI FUNCT DIFF 16-QFN |
9,820 |
|
- |
- | 16-VFQFN Exposed Pad | Tube | Obsolete | Configurable Multiple Function | 2 | 2 | No | Differential | - | 2.4V ~ 3.5V | -40°C ~ 85°C | - | - | Surface Mount | 16-QFN (3x3) |
|
MC100EP105FAR2IC GATE AND/NAND QUAD 2IN 32LQFP |
5,096 |
|
Datasheet |
100EP | 32-LQFP | Cut Tape (CT) | Obsolete | 2 Input AND/NAND Gate | 4 | 2 | No | Differential | - | 3V ~ 5.5V | -40°C ~ 85°C | - | - | Surface Mount | 32-LQFP (7x7) |
|
NBSG86ABAIC SMART GATE SIGE DIFF 16FCBGA |
2,024 |
|
- |
- | 16-LBGA, FCBGA | Tube | Obsolete | Configurable Multiple Function | 2 | 2 | No | Differential | - | 2.375V ~ 3.465V | -40°C ~ 85°C | - | - | Surface Mount | 16-FCBGA (4x4) |
|
HMC725LC3CTR-R5IC GATE XOR/XNOR 13DBPS 16QFN |
8,832 |
|
Datasheet |
- | 16-LFQFN Exposed Pad | Tape & Reel (TR) | Active | XOR/XNOR Gate | 1 | 4 | No | Differential, Single-Ended | - | -3V ~ -3.6V | -40°C ~ 85°C | - | - | Surface Mount | 16-SMT (3x3) |
|
HMC721LC3CTRIC GATE XOR/XNOR 13DBPS 16QFN |
4,092 |
|
Datasheet |
- | 16-LFQFN Exposed Pad | Tape & Reel (TR) | Active | XOR/XNOR Gate | 1 | 4 | No | Differential, Single-Ended | - | -3V ~ -3.6V | -40°C ~ 85°C | - | - | Surface Mount | 16-SMT (3x3) |
|
HMC721LC3CTR-R5IC GATE XOR/XNOR 13DBPS 16QFN |
7,964 |
|
Datasheet |
- | 16-LFQFN Exposed Pad | Tape & Reel (TR) | Active | XOR/XNOR Gate | 1 | 4 | No | Differential, Single-Ended | - | -3V ~ -3.6V | -40°C ~ 85°C | - | - | Surface Mount | 16-SMT (3x3) |
|
|
HMC722LC3CTR-R5IC GATE AND/NAND/OR/NOR 16QFN |
9,548 |
|
Datasheet |
- | 16-LFQFN Exposed Pad | Tape & Reel (TR) | Active | AND/NAND/NOR/OR GATE | 1 | 4 | No | Differential, Single-Ended | - | -3V ~ -3.6V | -40°C ~ 85°C | - | - | Surface Mount | 16-SMT (3x3) |
|
|
HMC726LC3CTR-R5IC GATE AND/NAND/OR/NOR 16QFN |
5,842 |
|
Datasheet |
- | 16-LFQFN Exposed Pad | Tape & Reel (TR) | Active | AND/NAND/NOR/OR GATE | 1 | 4 | No | Differential, Single-Ended | - | -3V ~ -3.6V | -40°C ~ 85°C | - | - | Surface Mount | 16-SMT (3x3) |
|
HMC745LC3TR-R5IC GATE XOR/XNOR 13DBPS 16CQFN |
6,572 |
|
Datasheet |
- | 16-VFCQFN Exposed Pad | Tape & Reel (TR) | Active | XOR/XNOR Gate | 1 | 4 | No | Differential, Single-Ended | - | 3V ~ 3.6V | -40°C ~ 85°C | - | - | Surface Mount | 16-CSMT (3x3) |
|
|
HMC746LC3CTR-R5IC GATE AND/NAND/OR/NOR 16QFN |
5,334 |
|
Datasheet |
- | 16-LFQFN Exposed Pad | Tape & Reel (TR) | Active | AND/NAND/NOR/OR GATE | 1 | 4 | No | Differential, Single-Ended | - | 3V ~ 3.6V | -40°C ~ 85°C | - | - | Surface Mount | 16-SMT (3x3) |
|
|
HMC851LC3CTRIC GATE XOR/XNOR 28GBPS 16QFN |
4,950 |
|
Datasheet |
- | 16-LFQFN Exposed Pad | Tape & Reel (TR) | Active | XOR/XNOR Gate | 1 | 4 | No | Differential, Single-Ended | - | -3V ~ -3.6V | -40°C ~ 85°C | - | - | Surface Mount | 16-SMT (3x3) |
