Single Bipolar Transistors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Transistor Type | Current - Collector (Ic) (Max) | Voltage - Collector Emitter Breakdown (Max) | Vce Saturation (Max) @ Ib, Ic | Current - Collector Cutoff (Max) | DC Current Gain (hFE) (Min) @ Ic, Vce | Power - Max | Frequency - Transition | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
2SD20640STRANS NPN 120V 6A TOP-3F-A1 |
13,152 |
|
Datasheet |
- | TOP-3F | Bulk | Obsolete | NPN | 6 A | 120 V | 2V @ 400mA, 4A | 50µA (ICBO) | 80 @ 1A, 5V | 3 W | 20MHz | 150°C (TJ) | - | - | Through Hole | TOP-3F-A1 |
|
2SA1952TLQTRANS PNP 60V 5A CPT3 |
5,358 |
|
Datasheet |
- | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Not For New Designs | PNP | 5 A | 60 V | 500mV @ 200mA, 4A | 10µA (ICBO) | 120 @ 1A, 2V | 1 W | 80MHz | 150°C (TJ) | - | - | Surface Mount | CPT3 |
|
CJD122 TR13TRANS NPN DARL 100V 8A DPAK |
15,340 |
|
- |
- | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Obsolete | NPN - Darlington | 8 A | 100 V | 4V @ 80mA, 8A | 10µA | 1000 @ 4A, 4V | 1.75 W | 4MHz | -65°C ~ 150°C (TJ) | - | - | Surface Mount | DPAK |
|
MJE5852TRANS PNP 400V 8A TO-220 |
8,630 |
|
Datasheet |
- | TO-220-3 | Tube | Obsolete | PNP | 8 A | 400 V | 5V @ 3A, 8A | 500µA | 5 @ 5A, 5V | 80 W | - | 150°C (TJ) | - | - | Through Hole | TO-220 |
|
2SC5200TRANS NPN 230V 15A TO-264 |
9,124 |
|
Datasheet |
- | TO-264-3, TO-264AA | Tube | Obsolete | NPN | 15 A | 230 V | 3V @ 800mA, 8A | 5µA (ICBO) | 55 @ 1A, 5V | 150 W | 30MHz | 150°C (TJ) | - | - | Through Hole | TO-264 |
|
2SC4445TRANS NPN 800V 3A TO-3PF |
15,734 |
|
Datasheet |
- | TO-3P-3 Full Pack | Bulk | Active | NPN | 3 A | 800 V | 500mV @ 140mA, 700mA | 100µA (ICBO) | 10 @ 700mA, 4V | 60 W | 15MHz | 150°C (TJ) | - | - | Through Hole | TO-3PF |
|
2SC5101TRANS NPN 140V 10A TO-3PF |
15,296 |
|
Datasheet |
- | TO-3P-3 Full Pack | Bulk | Active | NPN | 10 A | 140 V | 500mV @ 500mA, 5A | 10µA (ICBO) | 50 @ 3A, 4V | 80 W | 20MHz | 150°C (TJ) | - | - | Through Hole | TO-3PF |
|
2SB1259TRANS PNP DARL 120V 10A TO-220F |
6,464 |
|
Datasheet |
- | TO-220-3 Full Pack | Bulk | Active | PNP - Darlington | 10 A | 120 V | 1.5V @ 10mA, 5A | 10µA (ICBO) | 2000 @ 5A, 4V | 30 W | 100MHz | 150°C (TJ) | - | - | Through Hole | TO-220F |
|
2C2906A-MSCLSMALL-SIGNAL BJT |
9,276 |
|
- |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
2C2905SMALL-SIGNAL BJT |
12,500 |
|
- |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
FJAFS1720TUTRANS NPN 800V 12A TO-3PF |
14,672 |
|
Datasheet |
ESBC™ | TO-3P-3 Full Pack | Tube | Obsolete | NPN | 12 A | 800 V | 250mV @ 3.33A, 10A | 100µA | 8.5 @ 11A, 5V | 60 W | 15MHz | -55°C ~ 125°C (TJ) | - | - | Through Hole | TO-3PF |
|
CJD45H11 TR13TRANS PNP 80V 8A DPAK |
15,860 |
|
- |
- | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Obsolete | PNP | 8 A | 80 V | 1V @ 400mA, 8A | 10µA | 40 @ 4A, 1V | 1.75 W | 50MHz | -65°C ~ 150°C (TJ) | - | - | Surface Mount | DPAK |
|
NJL1302DTRANS PNP 260V 15A TO-264 |
15,286 |
|
Datasheet |
- | TO-264-5 | Tube | Obsolete | PNP | 15 A | 260 V | 3V @ 1A, 10A | 50µA (ICBO) | 75 @ 5A, 5V | 200 W | 30MHz | -65°C ~ 150°C (TJ) | - | - | Through Hole | TO-264 |
|
|
NJL3281DTRANS NPN 260V 15A TO-264 |
8,848 |
|
Datasheet |
- | TO-264-5 | Tube | Obsolete | NPN | 15 A | 260 V | 3V @ 1A, 10A | 50µA (ICBO) | 75 @ 5A, 5V | 200 W | 30MHz | -65°C ~ 150°C (TJ) | - | - | Through Hole | TO-264 |
|
MJ15002GTRANS PNP 140V 15A TO204 |
10,388 |
|
Datasheet |
- | TO-204AA, TO-3 | Tray | Obsolete | PNP | 15 A | 140 V | 1V @ 400mA, 4A | 250µA | 25 @ 4A, 2V | 200 W | 2MHz | -65°C ~ 200°C (TJ) | - | - | Through Hole | TO-204 (TO-3) |
|
MJ4032TRANS PNP DARL 100V 16A TO-3 |
5,392 |
|
Datasheet |
- | TO-204AA, TO-3 | Bulk | Obsolete | PNP - Darlington | 16 A | 100 V | 2.5V @ 40mA, 10A | 3mA | 1000 @ 10A, 3V | 150 W | - | 200°C (TJ) | - | - | Chassis Mount | TO-3 |
|
2SD2439TRANS NPN DARL 150V 10A TO-3PF |
7,802 |
|
Datasheet |
- | TO-3P-3 Full Pack | Bulk | Active | NPN - Darlington | 10 A | 150 V | 2.5V @ 7mA, 7A | 100µA (ICBO) | 5000 @ 7A, 4V | 80 W | 55MHz | 150°C (TJ) | - | - | Through Hole | TO-3PF |
|
2SB11540QTRANS PNP 80V 10A TOP-3F-A1 |
18,828 |
|
Datasheet |
- | TOP-3F | Bulk | Obsolete | PNP | 10 A | 80 V | 1.5V @ 1A, 10A | 10µA (ICBO) | 90 @ 3A, 2V | 3 W | 30MHz | 150°C (TJ) | - | - | Through Hole | TOP-3F-A1 |
|
|
HD1530JLTRANS NPN 700V 26A TO-264 |
18,742 |
|
Datasheet |
- | TO-264-3, TO-264AA | Tube | Obsolete | NPN | 26 A | 700 V | 2.5V @ 3.25A, 13A | 200µA | 5 @ 13A, 5V | 200 W | - | 150°C (TJ) | - | - | Through Hole | TO-264 |
|
|
2SB1588TRANS PNP DARL 150V 10A TO-3PF |
17,222 |
|
Datasheet |
- | TO-3P-3 Full Pack | Bulk | Active | PNP - Darlington | 10 A | 150 V | 2.5V @ 7mA, 7A | 100µA (ICBO) | 5000 @ 7A, 4V | 80 W | 50MHz | 150°C (TJ) | - | - | Through Hole | TO-3PF |
